ALC Panel Section
Shandong weida construciton machinery Co.,Ltd is located in Linyi, Shandong Province, the capital of logistics in China. It has a superior geographical location and convenient transportation. It has invested 160 million yuan and covers an area of 5,3000 square meters. It is a high-starting-point enterprise guided by science and technology.
Our range of popular products primarily comprises sand slurry ball mill machine for AAC block, AAC block crossing cutting machine, AAC block vertical cutting machine, and AAC block mould boxs, among others.
Why Choose us
Strong Team
Equipped with exceptional professional skills and extensive manufacturing experience, our team comprises 18 senior technicians and over 350 skilled professional and technical workers across various fields.
Our Certifications
Recognized as a Shandong High-tech Enterprise, we have obtained certifications such as ISO, CE, and SGS.
Advanced Production Equipment
We are equipped with a substantial array of precision machining tools as well as advanced inspection, testing, and debugging equipment. Our annual production capacity exceeds 300 sets of aerated concrete wall material equipment, pressure forming machines, and insulation board production lines.
Parameter
|
Model |
Maximum welding speed |
Maximum welding width |
Longitudinal bar spacing |
Transverse bar spacing |
Longitudinal bar dia |
Transverse bar dia |
Maximum welding capacity |
Longitudinal bar feeding mode |
Feed mode of transverse bar |
|
|
100 times/min |
≤500mm |
≥50mm |
≥20mm |
3-8mm |
3-8mm |
Dia8mm+dia6mm |
Preform |
Precut/automatic blanking (straightness 2mm/M) |
Ordering Process
Request a Quote
Please submit a request for a quote via our official website.
01
Place Your Order
Place an order of your liking after selecting your preferred shipping option.
02
Start Production
Production will start after design approval; the production takes about 3-4 weeks.
03
Quality Inspection
After complete production, the products undergo quality testing.
04
Shipping
The order is ready to take off to your place. Once it is shipped out we would let you know the tracking info.
05
Types of ALC Panel Section
The ALC panel section produced by our company mainly include the following types
Automatic Mesh Welding Machine For AAC Panel
The round steel plate material (cold drawn, hot rail can be) is automatically processed and welded into steel mesh sheet; The longitudinal bar enters the welding area through the guide parts, and the transverse bar falls through the blanking mechanism.
Saddle Steel Rod For AAC Panel
It is used to cooperate with the mold box to keep the cage in the mold box position. After the completion of repose, the steel brazing, saddle frame and assembly frame will be removed from the mold box, and the net cage will remain in the billet body in the predetermined position.
Insert Pull Rod Crane For AAC Panel
For the completion of mesh cage insertion and brazing operations; The assembled, anticorrosive and dried assembly frames are hoisted and placed in the pouring mold box, and the resting assembly frames are pulled out of the mold box and hoisted to the return position of the frame cycle.
ALC AAC Panel Conveyor
It is used for conveying sheet metal to facilitate the classification and packaging of sheet metal and block.
Benefits of ALC Panel Section
AAC Panel
AAC panel have many advantages, including
The mesh stepping mechanism is driven by a CNC servo motor, ensuring high precision and ease of adjustment;
A separable pay-off tray is incorporated into the design, featuring rational construction for rapid wire replacement;
Mesh specifications can be adjusted, with the spacing between longitudinal bars increasing in increments of 50mm. Adjustments to the spacing specifications are achieved through the opening or closing of the cylinder valve, providing convenient and precise control over mesh size;
The height of the electrode is adjustable, as is the transformer voltage, resulting in reduced production costs while maintaining flexibility and efficiency.
Additional Information
|
Terms Of Payment |
We usually accept T/T, L/C, Paypal, Credit card, etc. If you prefer other payments terms, please feel free to discuss with us. |
|
Packing Details |
Bubble wrap |
Certificate
